PCE offers full/ partial Turn-Key PCB Assembly Services for all kinds of active and passive components. All component suppliers are authorized and reliable. Now we can make PCBs, source components, and assemble products for you at only one stop. Prototyping & Mass Production inquiries are all welcome to ask.
Please provide:
- PCB Drawing (Gerber files or DXF)
- Bill of Materials (BOM)
- Quantity by each order
Assembly Capability
| Feature | Capability |
|---|---|
| Types of Assembly | SMT (Surface-Mount Technology) DIP (Thru-Hole Device) Hand Soldering Box Build |
| Components |
01005 components |
| Max Panel Size | 400*1200mm (15.7*47.2 inch) |
| E-Testing | AOI Functional Test X-Ray |
| Components | Speed per Sec | Quantity per Day |
|---|---|---|
| L.C.R Chips | 0.25~0.35sec | 240~336k pcs |
| Diode/ Tantalum | 0.45~0.55sec | 152~186k pcs |
| SOP/ QFN | 1.05~1.55sec | 54~67.2k pcs |
| SOJ/ PLCC/SOCKET | 2.05~5.55sec | 32.9~40k pcs |
| BGA/ QFP/ Connector | 2.55~3.05sec | 27.5~32.9k pcs |
